This is the schematic diagram of 400W RMS stereo power amplifier which use power transistor to work. This amplifier in addition to providing good sound power, also with excellent quality and a high fidelity with low noise, to obtain the 400 watts we can put 2 speakers of 4 Ohms or 4 of 8 Ohms.… Read More »
This is a small 12W audio amplifier over a load of 8 Ω, that combining the NE5534 integrated with a pair of V-MOSFET transistor output stage technology as we get excellent sound performance. MOSFET 2SK135 / 2SJ50 from Hitachi is used in this circuit. Input sensitivity of the circuit is 3V RMS maximum, the distortion factor… Read More »
This is the circuit diagram of 2000W class AB power amplifier uses 7 pairs MJ15003 and MJ15004 transistors for the final amplification block. The circuit operated with 90V DC symmetrical (dual polarity) power supply circuit. The transistors must be mounted on heatsink to prevent the overheating, maintain the transistors work in maximum performance.
This is linear power amplifier 2000 Watt which need advance knowledge in electronics since the schematic diagram is very complex for hand made circuit. I think you have to re-design the schematic diagram using circuit diagram software designer such as diptrace, eagle, expresspcb ect. Or just order the PCB online, they will be glad to… Read More »
This is 1.5W audio amplifier circuit design based on wide bandwidth, low distortion power IC SSM2211 from Analog Devices. This circuit is simple, inexpensive and easy to built with only contains few components. The SSM22111 is a high performance audio amplifier that delivers 1 W RMS of low distortion audio power into a bridge-connected 8… Read More »
This is the circuit diagram of 24 Watt class A linear audio amplifier, built and tested by Marc Klynhans from South Africa. The supply voltage can be between 34V and 46V and the quiescent current should be set to 1.7A measured through R25 (a voltage of 0.75V must be measured over R25 for a quiescent… Read More »
