This is the circuit diagram of power amplifier 45W using power uPC 1230 as the main component. The pre amp head has been added in the circuit using uPC 1032. This is an popular old circuit for hobbysts and the 45 Watt amplifier circuit should be working fine since the PCB already on the market… Read More »
This is the 300W RMS stereo power amplifier circuit project. This amplifier is based four pieces of power IC TDA7294. It’s mean that every single channel of the circuit uses two ICs in bridge mode. In this application, the load value must not be less than 8 Ohms.
This is a very interesting circuit design to assemble. There are 4in1 amplifier module in a circuit board. 100W power amplifier using the TDA7294, for the VU meter uses IC LM3914. The tone control preamp uses the well-known IC 4558. The symmetrical power supply module also included in the PCB.
This is 120W power amplifier schematic using TO-3 package complementary transistors, NPN and PNP polarity. The well-known power transistor pair of 2N3055 and MJ2955 used in this circuit. +/- 50V symmetrical (split/dual polarity) power supply with minimum 3A electric current should be used for maximum performance.
This is a 200W power amplifier circuit project. The circuit features high power, good definition and very low noise. It delivers about 200 watts in 4 ohms loudspeaker: a 4 ohm speaker or two pieces of 8 ohm speakers in parallel. This 200W power amplifier using the complementary transistors of 2SC5200 and 2SA1943 as the… Read More »
This is the schematic diagram of 400W RMS stereo power amplifier which use power transistor to work. This amplifier in addition to providing good sound power, also with excellent quality and a high fidelity with low noise, to obtain the 400 watts we can put 2 speakers of 4 Ohms or 4 of 8 Ohms.… Read More »
Here is the 250W RMS power amplifier circuit called Legend-Stage Master. This is the previous version of Legend-Stage Master MK2. The circuit is based on power MOSFET and give a great output performance for indoor audio sound system.
This is 500W RMS power amplifier circuit design, build based on MOSFET. The circuit is very popular in EE audio hobbyist as “LEGEND stage Master MK2”. It is a very good and powerful amplifier. It uses 12x power MOSFET IRFP240.
This is the circuit diagram of 70W OCL power amplifier with output power of 70 watts single channel. It uses power transistor TIP2955 and TIP3055 as main component. The power supply used for this amplifier is a symmetrical / dual polarity power supply with output voltage 25V – 32V. This amplifier dan be used to… Read More »
